Intel Core i7-3920XM

Intel 3920XM

Intel Core i7-3920XM var vid lanseringen i april 2012 den snabbaste fyrkärniga processorn i Intels Ivy Bridge-familj och följaktligen den snabbaste processorn för bärbara datorer vid lanseringen (petates dock ner från tronen i september 2012 av den något snabbare 3940XM).

Med hjälp av HyperThreading kan de fyra kärnorna hantera upp till åtta trådar parallellt. Varje kärna har en bashastighet på 2,9 GHz men processorn kan öka klockfrekvensen dynamiskt (med funktionen Turbo Boost) upp till 3,6 GHz med 4 aktiva kärnor, 3,7 GHz med2 aktiva kärnor och 3,8 GHz med 1 aktiv kärna – 100 MHz högre klockfrekvenser per steg jämfört med Core i7-3820QM.

Ivy Bridge är en optimerad version av föregångaren Sandy Bridge och tillverkas i 22nm istället för 32nm. Både GPU- och CPU-prestanda har förbättrats. Processorerna är först med ”tri-gate” (3D-transistorer) och är mer effektiva än Sandy Bridge-processorer med samma klockfrekvens. Andra nya funktioner är stöd för PCI Express 3.0 och DDR3 (L) 1600.

Prestandan med Core i7-3920XM är bättre än en Sandy Bridge-processor med samma klockfrekvens.  Resultatet är en förbättring på 10-15% jämfört med den tidigare toppmodellen Core i7-2960XM.

Den integrerade grafikkretsen Intel HD Graphics 4000 har 16 Execution Units (EUs) med en klockfrekvens på mellan 650 MHz upp till 1300 MHz med Turbo Boost.

XM-serien (Extreme Edition) har en TDP på 55 Watt, vilket kan jämföras med QM-modellernas 45 Watt och M-modellernas 35 Watt. Därför passar processorn bäst i stora bärbara datorer (17 tum eller större). Eftersom den tillhör Extreme Edition-serien är den olåst och kan överklockas i en laptop med tillräcklig strömförsörjning och kylning.

SerieIntel Core i7
KodnamnIvy Bridge

Serie: Core i7 Ivy Bridge

Intel Core i7-3940XM3 - 3.9 GHz4 / 8 cores8 MB L3
Intel Core i7-3920XM « 2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3840QM2.8 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-3820QM2.7 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-3740QM2.7 - 3.7 GHz4 / 8 cores6 MB L3
Intel Core i7-3720QM2.6 - 3.6 GHz4 / 8 cores6 MB L3
Intel Core i7-3635QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3630QM2.4 - 3.4 GHz4 / 8 cores6 MB L3
Intel Core i7-3615QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3610QM2.3 - 3.3 GHz4 / 8 cores6 MB L3
Intel Core i7-3632QM2.2 - 3.2 GHz4 / 8 cores6 MB L3
Intel Core i7-3612QM2.1 - 3.1 GHz4 / 8 cores6 MB L3
Intel Core i7-3540M3 - 3.7 GHz2 / 4 cores4 MB L3
Intel Core i7-3520M2.9 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-3687U2.1 - 3.3 GHz2 / 4 cores4 MB L3
Intel Core i7-3667U2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-3537U2 - 3.1 GHz2 / 4 cores4 MB L3
Intel Core i7-3517U1.9 - 3 GHz2 / 4 cores4 MB L3
Intel Core i7-3689Y1.5 - 2.6 GHz2 / 4 cores4 MB L3
Klockfrekvens2900 - 3800 MHz
Level 1-cache256 KB
Level 2-cache1 MB
Level 3-cache8 MB
Antal kärnor / trådar4 / 8
Strömförbrukning (TDP = Thermal Design Power)55 Watt
Antal transistorer1400 Miljon
Tillverkningsprocess22 nm
Kretsstorlek160 mm2
Max. temperatur105 °C
SockelFCPGA988
FunktionerHD Graphics 4000, DDR3(L)-1600 Memory Controller, HyperThreading, AVX, Quick Sync, Virtualization
GPUIntel HD Graphics 4000 (650 - 1300 MHz)
64-bit64-bitsstöd
Architecturex86
Pris från$1096 U.S.
Lanseringsdatum04/23/2012
Produktlänkark.intel.com

Prestandatester

Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 6.89     avg: 7.1     median: 7.1 (9%)     max: 7.22 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.53     avg: 1.6     median: 1.6 (37%)     max: 1.58 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 5045     avg: 5078     median: 5078 (31%)     max: 5111 poäng
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 19595     avg: 19653     median: 19652.5 (14%)     max: 19710 poäng
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 19756     avg: 23050     median: 24647 (16%)     max: 24748 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 5132     avg: 6011     median: 6416 (8%)     max: 6484 Points
wPrime 2.10 - wPrime 2.0 1024m *
min: 220.9     avg: 241.8     median: 241.8 (3%)     max: 262.7 s
wPrime 2.10 - wPrime 2.0 32m *
min: 7.412     avg: 7.5     median: 7.5 (2%)     max: 7.539 s
WinRAR - WinRAR 4.0
4570 poäng (7%)
X264 HD Benchmark 4.0 - x264 Pass 2
min: 37.1     avg: 38     median: 38 (13%)     max: 38.9 fps
X264 HD Benchmark 4.0 - x264 Pass 1
min: 156.4     avg: 156.7     median: 156.7 (36%)     max: 157 fps
TrueCrypt - TrueCrypt Serpent
min: 0.366     avg: 0.4     median: 0.4 (11%)     max: 0.373 GB/s
TrueCrypt - TrueCrypt Twofish
min: 0.562     avg: 0.6     median: 0.6 (10%)     max: 0.633 GB/s
TrueCrypt - TrueCrypt AES
min: 3.5     avg: 3.6     median: 3.6 (9%)     max: 3.6 GB/s
3DMark 06 - CPU - 3DMark 06 - CPU
min: 6793     avg: 6935     median: 6973 (15%)     max: 7039 Points
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 9     avg: 9.4     median: 9 (2%)     max: 10.11 s
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 22     avg: 22.3     median: 22 (1%)     max: 22.98 s
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 531     avg: 534     median: 534 (2%)     max: 537 s
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
min: 115400     avg: 129935     median: 129935 (62%)     max: 144470 MIPS
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
min: 83580     avg: 85345     median: 85345 (65%)     max: 87110 MFLOPS
Windows 7 Experience Index - Win7 CPU
7.7 Points (99%)
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
min: 24085     avg: 24928     median: 25094 (19%)     max: 25605 Points
3DMark 11 - 3DM11 Performance Physics
9329 Points (24%)
- Bredd på benchmark-värden för det här grafikkortet
- Genomsnittliga benchmark-värden för det här grafikkortet
* Smaller numbers mean a higher performance
